LUX Hydraulic Operator for Swing Gates up to 700lbs, leaf 15FT

Important. This product is intended to be installed and serviced by a professional technician. The product warranty may be voided if installed or serviced by an unqualified person.

Swing Gate Operator for leaf weight up to 700 lbs (~320kg), leaf length up to 15 feet (4.5m)

Lux operators are sold a la carte. One or two actuators, a controller, and accessories as needed.

SMART TECHNOLOGY FEATURES
> Integrated rolling code radio receiver
> Control unit with D-Track self-learning and self-diagnostic functions
> Control unit compatible with the U-link WIFI platform
> Contains obstruction sensing device

TECHNICAL FEATURES
> Capacity: 700 lbs and 15 Ft
> Cycle Time: 17 seconds
> Motor: 120 VAC
> Drive: Hydraulic
> Power Supply: 120 VAC, 60 Hz, Single Phase
> Radio Controls: 433MHz Rolling Code (integrated)
> Dimensions: 3-1/4"H x 3-1/4"W x 51"L
> Weight: 19 lbs
> MET Listed for UL, 325, Door, Drapery, Gate, Louver & Window Operator Systems
> BFT Easy Set app to help with the installation geometry on new swing gates.
> Mechanical Limit Switches
> Requires Positive Stops

USAGE
> Heavy Duty operator with Commercial & Industrial Focus
> Duty Cycle: 500 cycles/day
> Small footprint
> Warranty 2 years from install date
